Vietnam Cone Crusher Spare for Activated Carbon

Basic Info

Model NO.	PYS-B0917
Inlet Size	115mm
Condition	New
Warranty	1year
Capacity	50-180tph
Max Feeding Size	175mm
Adjustment Range	13-38mm
Weight	15t
Color	as Clients Request
Final Aggregate Size	0-5-10-20-40(Changable)
Spare Part Supply	Lifelong
Foundation	Concrete Foundation or Steel Structure
OEM	Yes
Factory Visit	Warmly Welcome
Transport Package	Container
Specification	PYB900
Trademark	shanman
Origin	China
HS Code	84742090
Production Capacity	50000/Year

Product Description

vietnam cone crusher spare for activated carbon1. PYS-B0917 cone crusher details Shanman model PBS-B0917 cone crusher is also called 3ft cone crusher, it is one kind of coarse crushing, usually used as secondary crushing. The feeding size is 160-170mm, adjustment range is 13-38mm. It is suitable for processing gravels, ores, slag and construction waste and used for second, three or four level crushing of stones and slag.
2. Sysmons cone crusher Introduction:Cone crusher is also a kind of spring safety type cone crusher, which concentrateson the specialty of high-frequency,optimization of cavity and reasonable impact.it is based on the conceptions of laminated crushing principle and more crushing and less grinding. there are 3',4' 4 1/4,51/2,7' five models of Symons cone crusher,each model with standard and short head type,and each type have its fine, medium,coarse cavity type. The symons cone crusher series,widely used in the industries of metallurgy,building material, road construction, chemical engineering & silicate, is suitable for crushing all kinds of ores and rocks with hardness of medium or above this machine features the high crushing ratio,high efficiency,high operation. the quality of material used for components and reasonable design of construction contributes to its longer running performance and even granularity of the crushed product in addition to reducing to the circulation load; and furthermore by introducing the hydraulic cleaning chamber system into the crusher of middle and large size, the down time is reduced accordingly,the user may choose different type of chamber upon different request freely, because of the wide range of products to be provided. Symons cone crusher are widely applied in metallurgy, construction, road building, chemical and phosphatic industry. It is suitable for hard and mid-hard rocks and ores, such as iron ores, copper ores, limestone, quartz, granite, grit stone, etc...Cavity type of the crushing is decided by the application of the ores. Standard type is applicable to medium crushing, middle type is applicable to fine crushing and short-head type is applicable to super fine crushing.

Item	Spcification
Max Feeding size	175mm
Capacity	50-180t/h
Weight	15t
Motor power	75kw
Adjustment Range	13-38mm
Machine includes	cone crusher, motor
Power supply	Electric

3. Working principleSysmons cone crusher Working Principle1. When the Mine barite Symons cone crusher is working, the engine rotates around a fixed point driven by the belt wheel or the coupling.2. The transmission shaft and the conical part of cone crusher swing under the force from the eccentric bushing, which makes the crushing wall of the Symons cone crusher close to the pierced mortar wall at intervals.3. Then, the ores will be impacted, squeezed and bent constantly in the crushing chamber.4. At last, the whole ore crushing process is finished.5. The perfect combination of high-performance crushing chamber and high crushing frequency improves the handling ability of conecrusher to a greater degree.



4. Sysmons cone crusher Features1. Unequaled output and uniform product throughout a wide range of capacities;2. High working efficiency, greater crushing force;3. Largest head displacement provides greater production capacity;4. Long lasting bearing with stand crushing loads and severe environmental conditions;5. Hydraulic controls providing fast setting changes and simply clearing;6. Long working life, low operating and maintenance costs;7. All parts can be exchanged with Symons cone crusher.

5.Sysmons cone crusher specifications

Model (Standard Type)	Broken Diameter (ft)(mm)	Feeding Size(mm)		Adjustment Range(mm)	Motor Power (kw)	Weight (t)	Capacity (t/h)
		Closing side	Opening side
PYS-B0917	3(Ft) 914	159	175	13-38	75	14.64	55-180
PYS-B1321	4-1/4(Ft) 1295	188	210	16-38	155	25.86	118-280
PYS-B1624	5-1/2(Ft) 1676	213	241	22-51	240	50.8	232-460
PYS-B2133	7(2FtHD) 2137	303	334	25-51	400	89.5	550-1098
Note: If there is any modification, all parameters are subject to the machine.

6. Details highlight the quality

7. Project cases

8.Customer visit



9. Certifications:

10. Shanman service

1. Assist clients to choose the suitable machine
2. Design and manufacture machines according to customer's special requirements
3. The company is free of charge to the user on-site engineering and technical personnel planning site for the user to design the best processes and program
4. Arrange for visiting our factory, assist them to handle relative procedure, such as visa.
5. Make sure goods prepared within delivery time;
6. Pre-check and accept products ahead of delivery;
7. Prepare documents required to help customer pass customs clearance.
8. Help clients to make Project evaluation and feasibility analysis and draft solving plans.
9. Provide technical engineers to guide the installation;
10. Train clients worker how to operate;
11. Offer spare parts at a best price for long term.

11. Packing & shipping



12.Questions you may haveQ: Are you mining machinery manufacturer?
A: Yes, we are manufacturer, we warmly welcome clients to visit our factory at anytime. We can also provide samples test, mine design, equipment manufacture, after-sale service, etc..
Q: how to choose the suitable machine?
A: To design a suitable machine, please let me know the following information:

1. what kind of stone do you want to crush ? like limestone ? or granite ?
2. what's the size of your stone before crush ? how many inch or mm ?
3. how big capacity do you need?2t/h?10t/h?100t/h?
4. what's your requirements of final product size ? how many inches or mm ?0-5mm?5-20mm? Or others?
5. you only need one set of crusher or a whole crushing line? (Include the feeder ,crusher, screen, conveyor and so on)
6. You need mobile crushing machine or stationary one?

Q: How long is the warranty of your machine? Does your company supply the spare parts?
A: the warranty period is one year. we will supply the spare parts for you any time
Q: If I buy a complete mineral processing line, can you help us to build it?
A: Yes, we can help you combine a complete mineral processing line and give you related professional advice. We had already build many mining projects in China & Overseas
Q: how about the installation?
A: Supplier provides a full set of installation drawings and instructions. If the buyer need supplier do the installation, supplier will provide technical engineers to guide the installation, and train buyer' workers. Buyer should take the charges for technicians and pay them salary. Q: what is the payment Method?
A: By T/T, L/C, Western Union, Money Gram, and so on. 13. Small series crusher machine



14. About us
Shanman Machinery Crusher Production Base is a company specializing in the production of jaw crushers, impact crushers, cone crushers, sand making machines, vibrating feeders, vibrating screens, mobile stone crushers and other crushing and screening machines. The company was founded in 2010, covers an area of 20,000 square meters, has more than 100 employees, 5 chief engineers and more than 10 after-sales service personnel, these can ensure your solution. Shanman has now become a production and export base for the crushing and screening industry.As a production plant, we can produce crushing and screening machines according to your actual needs. Many models we develop and produce are designed and produced according to different customer requirements. You can let us know your thoughts, and professional engineers will help you.Our missionCarry out independent and innovative research in the design field of crushing and screening equipment and devote to the production of the most suitable equipment.We are committed to producing high-quality and cheap machinery.Production of machines for people in need, production of the most suitable machinesOur visionEstablish a first-class production base to inject power into the crushing and screening industryJoin hands with Shanman to create a better future.
